Dao phay cầu 2me Dormer Pramet S233
Thông số kỹ thuật Dao phay cầu 2me Dormer Pramet S233
Code | Short Description | d1
Ø
mm | r
+0/-0.02
mm | d2
Øh6
mm | l2
mm | l1
mm |
z
| l3
mm | d3
Ø
mm |
S2332.0XD3 | 2.00 mm x 3.0 mm | 2.00 | 1.00 | 3 | 4 | 100 | 2 | 20.0 | 1.9 |
S2332.0XD4 | 2.00 mm x 4.0 mm | 2.00 | 1.00 | 4 | 4 | 100 | 2 | 20.0 | 1.9 |
S2333.0XD3 | 3.00 mm x 3.0 mm | 3.00 | 1.50 | 3 | 5 | 100 | 2 | 30.0 | 2.8 |
S2333.0XD6 | 3.00 mm x 6.0 mm | 3.00 | 1.50 | 6 | 5 | 100 | 2 | 30.0 | 2.8 |
S2334.0XD4 | 4.00 mm x 4.0 mm | 4.00 | 2.00 | 4 | 8 | 100 | 2 | 40.0 | 3.7 |
S2334.0XD6 | 4.00 mm x 6.0 mm | 4.00 | 2.00 | 6 | 8 | 100 | 2 | 40.0 | 3.7 |
S2335.0 | 5.00 mm | 5.00 | 2.50 | 5 | 9 | 100 | 2 | 50.0 | 4.6 |
S2336.0 | 6.00 mm | 6.00 | 3.00 | 6 | 10 | 100 | 2 | 60.0 | 5.5 |
S2338.0 | 8.00 mm | 8.00 | 4.00 | 8 | 12 | 100 | 2 | 60.0 | 7.4 |
S23310.0 | 10.00 mm | 10.00 | 5.00 | 10 | 14 | 125 | 2 | 85.0 | 9.2 |
S23312.0 | 12.00 mm | 12.00 | 6.00 | 12 | 16 | 125 | 2 | 85.0 | 11.0 |
S23314.0 | 14.00 mm | 14.00 | 7.00 | 14 | 32 | 150 | 2 | 110.0 | 13.0 |
S23316.0 | 16.00 mm | 16.00 | 8.00 | 16 | 32 | 150 | 2 | 110.0 | 15.0 |
